EXPOSURE XM-3 MM/MC PHONO STAGE

Available in black or titanium finish, the XM Series of components may be small in size but they’re big on features and performance. With unmatched levels of sound quality and clarity, the XM Series conveys the art of music replay with outstanding realism.

Features

• Large 200W custom made toroidal transformer for power supply

• Multiple power supply capacitors in parallel for low ESR

• All discrete transistor audio stages

• High quality resistors & capacitors used in the signal path

• Separate MM & MC inputs selectable on the back panel

• Adjustable loading & gain switches on the back panel

• High quality all aluminium case work and extruded front panel

•  Three year guarantee

• Available in black or titanium

Outputs

Frequency Response : 30Hz - 20kHz within +/- 0.25dB ref 1kHz with low frequency roll off below 30Hz

Total Harmonic @ 1kHz, ref 350mV out : <0.025% MC Input

Maximum Output Voltage : 7.8V RMS 1kHz

Output Impedance : 50 Ohms

Moving Magnet

Input Sensitivity : 3.5mV input for 350mV output, 40dB gain setting

Signal to Noise Ratio ref 1kHz & 350mV out :

• Gain Switch 4 ON : >70dB

• Gain Switch 4 OFF : >78dB

Moving Coil Input

Sensitivity : 350uV input for 350mV output, 60dB gain setting

Signal to Noise Ratio ref 1kHz & 350mV out : >67db A weighted, ALL gain switches (4-6)

General

Power Consumption : <25W

Dimensions (HxWxD) : 89mm x 218mm x 348mm

Net Weight : 4kg

This item will usually ship within 2-3 working days, but delays may be experienced depending on manufacturer's stockholding. Please contact us for stock availability.
