EMOTIVA BasX A2+ 2-CHANNEL POWER AMPLIFIER
The 160wpc EMOTIVA BasX A2+ 2-channel power amplifier is a stereo power amplifier providing two channels of amplification ideal for a stereo hi-fi system, and multiples for a home theatre system.
This item will usually ship within 1-3 working days.
The BasX A2 features a heavy-duty linear power supply, high-quality Class A/B amplification, transparent fault protection, and a trigger input and output. The BasX A2 also offers a convenient feature that allows the amp to switch on when an audio signal is detected at its input - which is especially useful if your preamp or receiver doesn't offer a trigger output. High quality industry standard unbalanced RCA inputs enable the BasX A2 to be used with almost any preamp or processor and audiophile grade five way speaker terminals accept banana plugs, spade lugs, or bare wire. These features combine to enable the BasX A2 to deliver true audiophile performance and sound quality at an amazingly affordable price.
The BasX A2 the ideal amplifier to serve as the foundation of a great sounding stereo system, to power the front main speakers on a surround sound system, or to upgrade the front left and right channels of your favorite surround sound receiver.
160 watts RMS per channel; 20 Hz – 20 kHz; THD < 0.1%; into 8 Ohms
250 watts RMS per channel; 1 kHz; THD < 1%; into 4 Ohms
Power Bandwidth (at rated power; 4 Ohm - 8 Ohm load): 20 Hz to 20 kHz (+ / – 0.07 dB)
Broad Band Frequency Response: 10 Hz to 80 kHz +0/-1.8 dB
THD + noise: < 0.02% (A-weighted); ref rated power
Signal to Noise Ratio (8 Ohm load): > 112 dB; ref rated power; (A-weighted)
Minimum Recommended Load Impedance (per channel): 4 Ohms (equals one 4 Ohm load or two paralleled 8 Ohm loads).
Damping Factor (8 Ohm load): > 500
Input Sensitivity (for rated power; 8 Ohm load): 1.2 V
Gain: 29 dB
Input Impedance: 27 kOhms
Input Connections: Unbalanced (RCA); one each per channel
Speaker Output Connections: Audiophile grade 5-way binding posts
Trigger Input: 5 – 12 V (AC or DC); <10 mA input current required.
Trigger Output: 12 VDC; can drive any load up to 120 mA.
115 VAC or 230 VAC @ 50 / 60 Hz (automatically detected)
The BasX A2 is protected against excessive operating temperature, shorted speaker connections, ground faults, and other common fault conditions
17” wide x 4” high x 15-1/2” deep (not including connectors)
21-1/2” wide x 8” high x 21” deep (boxed)
25.2 lbs (unboxed)
33 lbs (boxed)
